The Silva Ranger 3 6400/360 Green Military Compass is a high-quality compass designed for outdoor use in military and tactical situations. It features a durable, green aluminium housing that is resistant to shock, water, and corrosion.
The compass has a clear baseplate with a 1:25,000 and 1:50,000 scale for easy map reading, as well as a clinometer for measuring slope angle. It also has a sighting mirror that allows for accurate bearings when sighting on distant objects.
The Silva Ranger 3 compass is equipped with a declination adjustment system that allows for quick and easy adjustment of the compass to account for local magnetic variation. This feature ensures that the compass readings are accurate and reliable.
The compass is also equipped with luminous markings that allow for easy reading in low-light conditions. The Ranger 3 compass comes with a lanyard for easy carrying, as well as a protective carrying case.
Overall, the Silva Ranger 3 6400/360 Green Military Compass is a high-quality compass that is ideal for military and outdoor use. Its durable construction, accurate readings, and easy-to-use features make it a reliable tool for navigating in challenging environments.
Product Specification
• SKU: 36896-1511
• Magnifying lens
• Illumination – 6 hours
• Scales: 1:25 000 and 1:50 000
• Luminous compound: Everglow
• Graduation: 6400 military mils and 360 degrees
• Declination adjustment: Declination scale in capsule
• Silva 1-2-3 system baseplate compass
• Complete with Lanyard
• Available graduations: 6400/360
• Resolution degrees/mils: 2 / 50
• Measuring scales on base plate: 1:25k, 1:50k, mm
• UTM position plotting scales (Romer scales): No
• Settling time from 90 degree angle within +/- 3 deg: 2.7 seconds
• Settling time from 90 degree angle to complete rest: 5 seconds
• Accuracy: +/- 1 degree (17.5 mils)
• Waterproof: IP68 - (more than 100 m)
• Altitude use: 5000m@-15 C
• Impact resistance: 30g in XYZ directions and free fall from 1.5mm height into gravel
• Temperature operating range: -40 to +60 oC
• Material: Acrylic
• Size: 106x54x10mm
